Selecting Performance Monitoring Tools

Linux Performance Observability Tools by Brendan Gregg (CC BY-SA 4.0)

System monitoring is a helpful approach to provide the user with data regarding the actual timing behavior of the system. Users can perform further analysis using the data that these monitors provide. One of the goals of system monitoring is to determine whether the current execution meets the specified technical requirements.

These monitoring tools retrieve commonly viewed information, and can be used by way of the command line or a graphical user interface, as determined by the system administrator. These tools display information about the Linux system, such as free disk space, the temperature of the CPU, and other essential components, as well as networking information, such as the system IP address and current rates of upload and download.

Monitoring Tools

The Linux kernel maintains counterstructures for counting events, that increment when an event occurs. For example, disk reads and writes, and process system calls, are events that increment counters with values stored as unsigned integers. Monitoring tools read these counter values. These tools provide either per process statistics maintained in process structures, or system-wide statistics in the kernel. Monitoring tools are typically viewable by non-privileged users. The ps and top commands provide process statistics, including CPU and memory.

Monitoring Processes Using the ps Command

Troubleshooting a system requires understanding how the kernel communicates with processes, and how processes communicate with each other. At process creation, the system assigns a state to the process.

Use the ps aux command to list all users with extended user-oriented details; the resulting list includes the terminal from which processes are started, as well as processes without a terminal. A ? sign in the TTY column represents that the process did not start from a terminal.

[[email protected]]$ ps aux
USER   PID %CPU %MEM    VSZ   RSS TTY      STAT START TIME COMMAND
user  1350  0.0  0.2 233916  4808 pts/0    Ss   10:00   0:00 -bash
root  1387  0.0  0.1 244904  2808 ?        Ss   10:01 0:00 /usr/sbin/anacron -s
root  1410  0.0  0.0      0     0 ?        I    10:08   0:00 [kworker/0:2...
root  1435  0.0  0.0      0     0 ?        I    10:31   0:00 [kworker/1:1...
user  1436  0.0  0.2 266920  3816 pts/0    R+   10:48   0:00 ps aux

The Linux version of ps supports three option formats:

  • UNIX (POSIX) options, which may be grouped and must be preceded by a dash.
  • BSD options, which may be grouped and must not include a dash.
  • GNU long options, which are preceded by two dashes.

The output below uses the UNIX options to list every process with full details:

[[email protected]]$ ps -ef
UID        PID  PPID  C STIME TTY          TIME CMD
root         2     0  0 09:57 ?        00:00:00 [kthreadd]
root         3     2  0 09:57 ?        00:00:00 [rcu_gp]
root         4     2  0 09:57 ?        00:00:00 [rcu_par_gp]
...output omitted...

Key Columns in ps OutputPID

This column shows the unique process ID.TIME

This column shows the total CPU time consumed by the process in hours:minutes:seconds format, since the start of the process.%CPU

This column shows the CPU usage during the previous second as the sum across all CPUs expressed as a percentage.RSS

This column shows the non-swapped physical memory that a process consumes in kilobytes in the resident set size, RSS column.%MEM

This column shows the ratio of the process’ resident set size to the physical memory on the machine, expressed as a percentage.

Use the -p option together with the pidof command to list the sshd processes that are running.

[[email protected] ~]$ ps -p $(pidof sshd)
  PID TTY      STAT   TIME COMMAND
  756 ?        Ss     0:00 /usr/sbin/sshd -D [email protected]
 1335 ?        Ss     0:00 sshd: user [priv]
 1349 ?        S      0:00 sshd: [email protected]/0

Use the following command to list of all processes sorted by memory usage in descending order:

[[email protected] ~]$ ps ax --format pid,%mem,cmd --sort -%mem
  PID %MEM CMD
  713  1.8 /usr/libexec/sssd/sssd_nss --uid 0 --gid 0 --logger=files
  715  1.8 /usr/libexec/platform-python -s /usr/sbin/firewalld --nofork --nopid
  753  1.5 /usr/libexec/platform-python -Es /usr/sbin/tuned -l -P
  687  1.2 /usr/lib/polkit-1/polkitd --no-debug
  731  0.9 /usr/sbin/NetworkManager --no-daemon
...output omitted...

Various other options are available for ps including the o option to customize the output and columns shown.

Monitoring Process Using top

The top command provides a real-time report of process activities with an interface for the user to filter and manipulate the monitored data. The command output shows a system-wide summary at the top and process listing at the bottom, sorted by the top CPU consuming task by default. The -n 1 option terminates the program after a single display of the process list. The following is an example output of the command:

[[email protected] ~]$ top -n 1
Tasks: 115 total,   1 running, 114 sleeping,   0 stopped,   0 zombie
%Cpu(s):  0.0 us,  3.2 sy,  0.0 ni, 96.8 id,  0.0 wa,  0.0 hi,  0.0 si,  0.0 st
MiB Mem :   1829.0 total,   1426.5 free,    173.6 used,    228.9 buff/cache
MiB Swap:      0.0 total,      0.0 free,      0.0 used.   1495.8 avail Mem

  PID USER      PR  NI    VIRT    RES    SHR S  %CPU  %MEM     TIME+ COMMAND
    1 root      20   0  243968  13276   8908 S   0.0   0.7   0:01.86 systemd
    2 root      20   0       0      0      0 S   0.0   0.0   0:00.00 kthreadd
    3 root       0 -20       0      0      0 I   0.0   0.0   0:00.00 rcu_gp
...output omitted...

Useful Key Combinations to Sort FieldsRES

Use Shift+M to sort the processes based on resident memory.PID

Use Shift+N to sort the processes based on process ID.TIME+

Use Shift+T to sort the processes based on CPU time.

Press F and select a field from the list to use any other field for sorting.

IMPORTANT

The top command imposes a significant overhead on the system due to various system calls. While running the top command, the process running the top command is often the top CPU-consuming process.

Monitoring Memory Usage

The free command lists both free and used physical memory and swap memory. The -b-k-m-g options show the output in bytes, KB, MB, or GB, respectively. The -s option is passed as an argument that specifies the number of seconds between refreshes. For example, free -s 1 produces an update every 1 second.

[[email protected] ~]$ free -m
              total        used        free      shared  buff/cache   available
Mem:           1829         172        1427          16         228        1496
Swap:             0           0           0

The near zero values in the buff/cache and available columns indicate a low memory situation. If the available memory is more than 20% of the total, and the used memory is close to the total memory, then these values indicate a healthy system.

Monitoring File System Usage

One stable identifier that is associated with a file system is its UUID, a very long hexadecimal number that acts as a universally unique identifier. This UUID is part of the file system and remains the same as long as the file system is not recreated. The lsblk -fp command lists the full path of the device, along with the UUIDs and mount points, as well as the type of file system in the partition. If the file system is not mounted, the mount point displays as blank.

[[email protected] ~]$ lsblk -fp
NAME        FSTYPE LABEL UUID                                 MOUNTPOINT
/dev/vda
├─/dev/vda1 xfs          23ea8803-a396-494a-8e95-1538a53b821c /boot
├─/dev/vda2 swap         cdf61ded-534c-4bd6-b458-cab18b1a72ea [SWAP]
└─/dev/vda3 xfs          44330f15-2f9d-4745-ae2e-20844f22762d /
/dev/vdb
└─/dev/vdb1 xfs          46f543fd-78c9-4526-a857-244811be2d88

The findmnt command allows the user to take a quick look at what is mounted where, and with which options. Executing the findmnt command without any options lists out all the mounted file systems in a tree layout. Use the -s option to read the file systems from the /etc/fstab file. Use the -S option to search the file systems by the source disk.

[[email protected] ~]$ findmnt -S /dev/vda1
TARGET SOURCE    FSTYPE OPTIONS
/      /dev/vda1 xfs    rw,relatime,seclabel,attr2,inode64,noquota

The df command provides information about the total usage of the file systems. The -h option transforms the output into a human-readable form.

[[email protected] ~]$ df -h
Filesystem      Size  Used Avail Use% Mounted on
devtmpfs        892M     0  892M   0% /dev
tmpfs           915M     0  915M   0% /dev/shm
tmpfs           915M   17M  899M   2% /run
tmpfs           915M     0  915M   0% /sys/fs/cgroup
/dev/vda1        10G  1.5G  8.6G  15% /
tmpfs           183M     0  183M   0% /run/user/1000

The du command displays the total size of all the files in a given directory and its subdirectories. The -s option suppresses the output of detailed information and displays only the total. Similar to the df -h command, the -h option displays the output into a human-readable form.

[[email protected] ~]$ du -sh /home/user
16K /home/user

Using GNOME System Monitor

The System Monitor available on the GNOME desktop provides statistical data about the system status, load, and processes, as well as the ability to manipulate those processes. Similar to other monitoring tools, such as the topps, and free commands, the System Monitor provides both the system-wide and per-process data. These monitoring tools retrieve commonly viewed information, and can be used by way of the command line or a graphical user interface, as determined by the system administrator. Use the gnome-system-monitor command to access the application from a command terminal.

To view the CPU usage, go to the Resources tab and look at the CPU History chart.

Figure 2.2: CPU usage history in System Monitor

The virtual memory is the sum of the physical memory and the swap space in a system. A running process maps the location in physical memory to files on disk. The memory map displays the total virtual memory consumed by a running process, which determines the memory cost of running that process instance. The memory map also displays the shared libraries used by the process.

Figure 2.3: Memory map of a process in System Monitor

To display the memory map of a process in System Monitor, locate a process in the Processes tab, right-click a process in the list, and select Memory Maps.
